YA-PS03 Hydraulic Patient Stretcher

Benefits of YA-PS03 hydraulic patient stretcher

The proper procedure needs to be exercised to safely transfer the patient from the stretcher to the bed. An innovative side-rail design allows medical personnel to carry out this action efficiently and with greater ease. Side-rail can be laid out on a bed positioned next to the stretcher to act as a transfer board, creating zero gaps for easy and quick transfer.

Main features

- Side rails can be fixed at a horizontal position for drip and puncture. Loading capacity 10kg.

- Using a 70mm thick sponge mattress, fabric is waterproof and breathable

- Style of P-shaped from and U-shaped back

- With 5th retractable wheel in the middle for direction

- Double Locks of Side Rails

- Using hydraulic cylinder and high-low hand crank and self-pill rod

- Using gas spring to stepless lift

与Ce -沉默的脚轮ntral Lock

——输液杆两边

Accessories

- Mattress

- IV pole

- Pushing handle

Options

- Monitor shelf

- X-ray translucent platform

Technical parameter

Overall size	2150*830*560-890mm
Back section adjustment	0-80°
Foot section adjustment	0-35°
Height adjustment	560-890mm
Trendelenburg	0-16°
Reverse trendelenburg	0-16°
Caster	Diameter 200mm
Size of the oxygen bottle holder	Dia. 140mm, max. 4L
Loading capacity	220kg
